Page 58

SECTION 5 - MACHINE OPERATION

5-4

– JLG Lift –

3121197

TOWER RAISED ENOUGH TO GET MAIN BOOM TO HORI-

ZONTAL

MACHINE WILL TIP OVER IN

DIRECTION OF ARROWS IF OVERLOADED

MAIN BOOM FULLY EXTENDED AND

HORIZONTAL

JIB HORIZONTAL

TURNTABLE IN

STOWED POSITION

Figure 5-3. Position of Least Forward Stability (T500J)
