SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
7-2 – JLG Lift – 3121197
Panel Tray Capacity (w/Rotator) 70 lbs. (32 kg) 70 lbs. (32 kg)
Panel Tray Capacity (w/o Rotator) 100 lbs.
(45 kg)
100 lbs.
(45 kg)
Swing 410°
non-continuous
410°
non-continuous
Max.Vertical Platform Height (Unrestricted) 35 ft.
(10.6 m)
50 ft.
(15.2 m)
Vertical Reach (unrestricted) 35 ft. (10.4 m) 50 ft. (15.2 m)
Horizontal Reach
(from centerline of machine)
(from outrigger pad edge)
20 ft. (6.1 m)
14 ft. (4.27 m)
31 ft. (9.45 m)
25 ft. (7.62 m)
Up and Over Clearance 15 ft. (4.57 m) 18 ft. (5.49 m)
Maximum Outrigger Pad Load 1950 lbs.
(885 kg)
2740
(1243 kg)
Maximum Ground Bearing Pressure 22.5 psi
(1.58 kg/cm 2 )
30.7 psi
(2.15 kg/cm 2 )
Maximum Travel Gradeability - ANSI, CSA, AUS (see
Figure 5-7.)
20% 20%
Maximum Travel Gradeability - CE
(see Figure 5-7.)
15% 15%
Maximum Sideslope - ANSI, CSA, AUS (see Figure 5-7.) 11° 11°
Table 7-1. Operating & Towing Specifications
MODEL T350 T500J
Maximum Sideslope - CE (see Figure 5-7.) 8.5° 8.5°
Max. Hydraulic System Pressure 2700 psi
(186 Bar)
2950 psi
(203 Bar)
Maximum Operating Wind Speed 28 mph
(12.5 m/s)
28 mph
(12.5 m/s)
Maximum Horizontal Manual Force 90 lb. force
(400 N)
90 lb. force
(400 N)
Electrical System Voltage - Electric Machine 24 volts 24 Volts
Electrical System Voltage - Gas Machine 12 volts 12 Volts
Gross Machine Weight (Platform Empty)
ANSI/CSA/Australian Machines
Note: Machine weight may increase with options.
3400 lbs.
(1542 kg)
4750 lbs.
(2155 kg)
Gross Machine Weight (Platform Empty)
CE Machines
Note: Machine weight may increase with options.
3748 lbs.
(1700 kg)
5776 lbs.
(2620 kg)
Table 7-1. Operating & Towing Specifications
MODEL T350 T500J
