SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121197 – JLG Lift – 7-5
Engine Batteries (Electric Machines)
Table 7-7. Engine Specifications
Type 4-stroke, overhead valve, single cylinder
Displacement 16.5 cu.in. (270 cm 3 )
Bore x Stroke 3.0 x 2.3 in. (77 x 58 mm)
Max. Output 9 bhp (6.6 kW) at 3,600 rpm
Max. Torque 14.1 ft.lbs. (19.1 Nm) at 2,500 rpm
Fuel Consumption 0.51 lb/hph (313 g/kWh, 230 g/PSh)
Fuel Type Unleaded gasoline with a pump octane
rating of 86 or higher
Spark Plug NGK: BPR6ES
DENSO: W20EPR-U
Spark Plug Gap 0.028 - 0.031 in. (0.70 - 0.80 mm)
Table 7-8. Engine Battery Specifications
BCI Group Size 51R
Cranking Performance 550 amps @ 32 °F (0°C)
450 amps @ 0 °F (-18°C)
Reserve Capacity 80 minutes @ 32 °F (0°C)
Table 7-9. Battery Specifications
Voltage 6-Volt
Amp Hour Rating @ 20 hour rate - 220
Reserve Capacity @ 75 Amps 110 Minutes
AT -40° F (-40° C) Open Circuit Voltage Greater or Equal to 6 Volts
Life Cycle Rating 600 Cycles
Internal Resistance No more than 2.5 mOhms @ 70° F (21° C) / 4.0
m Ohms @ 0° F (-18°C)
Battery Weight (minimum allowable) 61 lbs. (27.7 kg)
