SECTION 5 - CAT CHASSIS (S/N 0300128000 TO PRESENT)

5-20

– JLG Lift –

3121157

Inspection for Hydraulic Fluid and Lubricant Leaks, and Torque of Bolts and Plugs

Figure 5-20. Inspection of oil leak, bolts and plugs

1. Oil leak inspection location

2. Tightening torque of bolts

Oil leak inspection location

Tightening torque of

bolts and plugs
