RECOMMENDED SPARE PARTS
The following list will service fleets of machines (built to current production per date on the front cover) with repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
91474001
G6-42A
13-3
Wheel End Seal, (Axle S/N FITA733977 & After), (see Section 5)
4
Wheel End Bushing, (see Section 5)
4
Wheel Hub Seal, (see Section 5)
2
Universal Joint Kit, (S/N 0190001 thru 0190457& 0160000022 thru 0160000843),
(Carraro), (see Figure 5-40)
4
Universal Joint Kit, (S/N 0160000847 thru 0160020658), (Dana), (see Figure 5-40)
2
Universal Joint Kit, (S/N 0160020685 & After), (Dana), (see Figure 5-40)
4
HYDRAULIC SYSTEMS
Boom Joystick Assy, (if equipped), (see Figure 7-6)
1
Boom Joystick With Adjustable Tilt, (if equipped), (see Figure 7-6)
1
Boom Joystick Handle Assy, (if equipped), (see Figure 7-6)
1
Boom Joystick Handle With Wire & Connector, (if equipped), (see Figure 7-6)
1
Lift Cylinder Seal Kit, (S/N 0190001 thru 0160010475), (see Figure 9-1)
1
Lift Cylinder Seal Kit, (S/N 0160010497 thru 0160033619), (see Figure 9-1)
1
Lift Cylinder Seal Kit, (S/N 0160033656 & After), (see Figure 9-1)
1
Extend/Retract Cylinder Seal Kit, (S/N 0190001 thru 0190457 & 0160000022 thru
0160033619), (see Figure 9-2)
1
Extend/Retract Cylinder Seal Kit, (S/N 0160033656 & After), (see Figure 9-2)
1
Tilt Cylinder Seal Kit, (S/N 0190001 thru 0190457 & 0160000022 thru 0160033619),
(see Figure 9-3)
1
Tilt Cylinder Seal Kit, (S/N 0160033656 & After), (see Figure 9-3)
1
Comp Cylinder Seal Kit, (S/N 0190001 thru 0160017476), (see Figure 9-4)
1
Comp Cylinder Seal Kit, (S/N 0160017503 & After), (see Figure 9-4)
1
Frame Level Cylinder Seal Kit, (S/N 0190001 thru 0190446), (see Figure 9-5)
1
Frame Level Cylinder Seal Kit, (S/N 0190447 thru 0190457 & 0160000022 thru
0160033619), (see Figure 9-5)
1
Frame Level Cylinder Seal Kit, (S/N 0160033656 & After), (see Figure 9-5)
1
Hydraulic Filter Element, (Before S/N 0160040678), (see Figure 9-8)
1
Hydraulic Filter, (S/N 0160040678 & After), (see Figure 9-8)
1
Tank Filter, (Before S/N 0160040678), (see Figure 9-8)
1
Tank Filter, (Before S/N 0160040678), (see Figure 9-8)
1
Breather, (see Figure 9-8)
1
Fluid Level Gauge, (Before S/N 0160040678), (see Figure 9-8)
1
Fluid Level Gauge, (S/N 0160040678 & After), (see Figure 9-8)
1
Bar Gauge, (Before S/N 0160040678), (see Figure 9-8)
1
ELECTRICAL
Water Temperature Sender, (Before S/N 0160040678), (John Deere), (see Figure 4-1)
1
Water Temperature Sender, (S/N 0160021195 thru 0160040659), (Perkins),
(see Figure 4-3)
1
Transmission Temp Switch, (S/N 0190001 thru 0160002053), (see Figure 4-1)
1
Transmission Temp Switch, (S/N 0160003208 & After), (see Figure 4-2)
1
Oil Press Switch, (Before S/N 0160040678), (John Deere), (see Figure 4-1)
1
Oil Press Sender, (Before S/N 0160040678), (see Figure 4-1)
1
Fuel Level Sender, (Before S/N 0160020148), (see Figure 4-8)
1
Fuel Level Sender, (S/N 0160020148 & After), (see Figure 4-8)
1
Part Number
Description
Qty./Machine
