JLG G6-42A Parts Manual - Manual (Page 754)

OPTIONS
G6-42A 91474001 12-110
Figure 12-35 Work Light Installation
Item Part Number Qty. Description Rev.
1001090468 Ref WORK LIGHT INSTALLATION, (not available to order, see items 1 thru 28 for
service) H
1 0641407 5 HEX HD CAPSCREW, 1/4-20X7/8, GR5
2 0641814 2 HEX HD CAPSCREW, 1/2-13X1-3/4, GR5
3 0903661 1 BOOM LIGHT MOUNTING BRACKET
4 3311401 5 HEX NUT, 1/4-20
5 3311801 2 HEX NUT, 1/2-13
6 4711400 8 FLAT WASHER, 1/4
7 4711800 8 FLAT WASHER, 1/2
8 1001095342 3 FLOOD LIGHT ASSY, (includes items 101 thru 103) B
80964070 3 BULB
9 85941016 3 CLAMP
10 Ref BOOM WORK LIGHTS HARNESS, (see Figure 10-16 for details)
11 1001090580 2 FLOOD LIGHT ASSY, (includes items 201 thru 205) B
13 1001090581 1 BEACON/FLOODLIGHT INSTALLATION, (includes items 301 thru 311) D
14 4761400 5 LOCKWASHER, 1/4
15 8096D097 8.3 ft WIRING DUCT
16 1001090460 1 WORK LIGHTS SWITCH
17 1001090461 1 BEACON SWITCH
18 Ref CAB WORK LIGHTS HARNESS, (see Figure 10-15 for details)
19 Ref CAB WORK LIGHT & BEACON LIGHT SWITCH HARNESS,
(see Figure 10-17 for details)
20 1001090522 1 BACK-UP LIGHT MOUNTING BRACKET
21 0642210 1 HEX HD CAPSCREW, 3/4-10X1-1/4, GR5
22 4712200 1 WASHER, 3/4
23 14404173 AR SILICONE SEALANT
24 8406105 1 CLIP
25 0641608 1 HEX HD CAPSCREW, 3/8-16X1, GR5
26 77363265 1 RELAY
27 80964009 1 FUSE
28 4761800 2 LOCKWASHER, 1/2
101 4460464 2 PIN TERMINAL
102 4460897 1 2 POSITION TERMINAL
103 80963050 1 FLOOD LIGHT ASSY A, 1
80964070 2 BULB
201 4460464 2 PIN TERMINAL
202 4460897 1 2 POSITION TERMINAL
203 80963050 1 FLOOD LIGHT ASSY A, 1
80964070 1 BULB
204 91403503 1 SPACER
205 91413052 1 WORK LIGHT MOUNTING BOLT
301 0903669 1 BEACON BRACKET
302 4460464 4 PIN TERMINAL
303 4460897 2 2 POSITION TERMINAL
304 1001099276 1 FLOOD LIGHT ASSY A
80964070 1 BULB
305 91343031 1 ROTATING BEACON
91344053 1 BULB
306 1001090615 1 GROMMET
S/N 0160031634 thru 0160040659
