Page 68
SECTION 1 - FRAME
68
3369LE/4069LE/M4069/M3369
3121123
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
31
4922454
2
Harness (See ELECTRICAL SECTION for Breakdown)
32
4922455
2
Harness (See ELECTRICAL SECTION for Breakdown)
33
4922456
1
Harness (Not Shown - See ELECTRICAL SECTION for
Breakdown)
4641150
Ref
LEVELING JACK CONTROL VALVE ASSEMBLY
B
101
0561407
1
Valve, Jack Control
102
2220883
2
Plug
103
4641151
2
Cartridge, Relief Valve
103
7021653
2
Seal Kit - 4641151 Valve (1 Per Cartridge)
104
4641152
2
Valve, 4-Way
104
7012903
2
Seal Kit - 4641152 Valve (1 Per Cartridge)
104
7012943
4
Coil (2 Per Cartridge)
0010572
Ref
LEVELING JACK DECALS INSTALLATION
201
Ref
Decal - Load Options:
201
1704955
4
Decal - Load (3369LE & M3369)
201
1704954
4
Decal - Load (4069LE & M4069)
202
Ref
Decal - Crush Warning Options:
202
1701214
8
ANSI and ANSI Export Specs
202
1704698
8
Brazilian Spec
202
1704690
8
CSA Spec
202
1704536
8
Japanese Spec
202
1704697
8
Latin American Spec
301
1001131751
Ref.
ROD REPLACEMENT KIT (INCLUDES ITEMS 1, 2, 6, 15, 16, 19 &
23)
A
