SECTION 1 - FRAME
3121123 3369LE/4069LE/M4069/M3369 65
FIGURE 1-17. LADDER AND BEACON INSTALLATIONS
ITEM PART NUMBER QTY DESCRIPTION REV
Ref LADDER INSTALLATION
0259576 Ref 3369LE & M3369 without Leveling Jacks E
0270514 Ref 3369LE & M3369 with Leveling Jacks B
0259577 Ref 4069LE & M4069 without Leveling Jacks E
0270514 Ref 4069LE & M4069 with Leveling Jacks B
1 0641828 4 Bolt 1/2in 13NC x 3 1/2in
1 0641824 4 Bolt 1/2in 13NC x 3in
2 3311805 4 Nut 1/2in -16NC
3 3520071 NLA Cap (use p/n 1001109533)
4 4751800 8 Flatwasher 1/2in
5 Ref Ladder Options:
5 4846159 1 Without Leveling Jacks
5 4846282 1 With Leveling Jacks
0259593 Ref BEACON LIGHT INSTALLATION (OPTIONAL) C
103 2820018 AR Tube, Heat Shrink (Not Shown)
104 2920146 1 Beacon Light Assembly
104 7016319 1 Tube, Flash
104 7016372 1 Lens, Replacement Amber
105 3941004 2 Screw, Self-Tapping #10-24NC x 1/2in
111 4922426 1 Harness, Beacon (Not Shown - See ELECTRICAL SECTION for
Breakdown)
