SECTION 1 - FRAME
3121123 3369LE/4069LE/M4069/M3369 59
FIGURE 1-14. BATTERY CHARGER ASSEMBLY (DELTA-Q CHARGER)
ITEM PART NUMBER QTY DESCRIPTION REV
1001103105 Ref BATTERY CHARGER ASSEMBLY A
2 Not Available 1 Harness with Connector
2 1001116811 1 Receptacle, Female - 4 Position
2 4460508 4 Pin, Male
3 Not Available 1 Harness with Connector
3 4460930 1 Plug, Male - 8 Position
3 4460464 7 Socket, Female
4 Not Available 1 Connector, Strain Relief
5 Not Available 1 Connector, Strain Relief
6 Not Available 1 Connector, Strain Relief
7 Not Available 1 Harness with Connector
101 2915230 1 BATTERY CHARGER REPROGRAM CONTROLLER (was p/n
1600466)
