SECTION 7 - ELECTRICAL
3121123 3369LE/4069LE/M4069/M3369 173
ITEM PART NUMBER QTY DESCRIPTION REV
418E Ref Connector Options:
418E 4460894 1 Plug, Male - 6 Position
418E 4460931 1 Receptacle, Female - 8 Position
418E 4460464 AR Pin, Male
418E 4460465 AR Socket, Female
418E 4460466 AR Plug, Sealing
419 Not Available 1 Harness, Speed Sensor (4WD Only)
419A 7024928 1 Receptacle, Female - 4 Position
419A 4460464 AR Pin, Male
420 70000328 1 Harness, Generator Control (M3369 & M4069)
420A 4460224 1 Connector, Female - 6 Position
420A 4460226 5 Socket, Female
420B 4460761 1 Connector, Female - 4 Position
420B 4460227 4 Pin, Male
421 Ref Harness, Generator Options:
421 4922529 1 M3369 & M4069 with Leveling Jacks (See OPTIONAL
ELECTRICAL COMPONENTS INSTALLATION for Breakdown)
421 4922602 1 M3369 & M4069 without Leveling Jacks A
421A 4460225 1 Plug, Male - 6 Position
421A 4460227 4 Pin, Male
421B 4460896 1 Plug, Male - 24 Position
421C 4460465 4 Socket, Female
424 Ref Harness, Motor/Generator Options:
424 7023486 1 Yanmar Engine
424 70000328 1 Kubota Engine
424 70000329 1 Fuse 15 Amp (Kubota Engine)
424 70000330 1 Fuse 20 Amp (Kubota Engine)
425 Not Available 1 Harness, Controller (Part of Electrical Assembly)
425A 4460265 1 Plug, Male - 9 Position
425A 4460268 8 Socket, Female
426 Ref Plug Options:
426 4460803 1 110VAC/60HZ (ANSI Spec)
426 Not Available 120V-240VAC/50-60HZ (ANSI Export)
426 4460805 1 250VAC/50HZ (ANSI Export)
426 4460803 1 100VAC 50/60HZ (Japanese Spec)
427 4460802 1 Cover, Plug
428 4460428 1 Connector, Strain Relief
