SECTION 4 - PLATFORM
3121123
3369LE/4069LE/M4069/M3369
113
FIGURE 4-2. FOLDDOWN HANDRAILS AND EXTENSION INSTALLATION (MANUALLY OPERATED
PLATFORM)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
FOLDDOWN HANDRAILS INSTALLATIONS OPTIONS:
0259566
Ref
Chain Gate
G
0259568
Ref
Self-Closing Welded Gate
I
1
4846123
2
Side Rail Weldment
2
4846124
1
Rear Rail Weldment (Left Side)
3
4846125
1
Rear Rail Weldment (Right Side)
4
4846122
1
Gate Weldment (Self-Closing Gate Only)
5
2600253
2
Hinge (Self-Closing Gate Only)
6
2080069
12
Fastener #10-32NF (Self-Closing Gate Only)
7
3900267
12
Screw, Socket Head (Self-Closing Gate Only)
8
2940074
1
Latch (Self-Closing Gate Only)
9
3571829
1
Plate, Latch
10
4845829
2
Retainer, Rail (Chain Gate Only)
11
0901870
2
Bracket
12
3421565
AR
Pin, Snap
13
3760170
AR
Ring, Split
14
1260136
2 ft/61cm
Chain (Chain Gate Only)
14
3010088
2
Link (Chain Gate Only)
15
0641516
3
Bolt 5/16in-18NC x 2in
16
Ref
Nut Options:
16
3300356
10
Nut, Acorn 5/16in-18NC
16
2080064
10
Nut, Nylon Lock 5/16in-18NC
17
3300432
4
Nut, Acorn #10-24NC (Self-Closing Gate Only)
18
3311505
3
Locknut 5/16in-18NC
19
3911010
4
Screw #10-24NC x 3/4in (Self-Closing Gate Only)
20
2820097
2 ft/.6m
Tubing, Mesh (Chain Gate Only)
21
3900323
9
Screw 5/16in-18NC x 2in (was p/n 3911532)
22
4751000
12
Flatwasher #10 Regular (Self-Closing Gate Only)
23
4751500
6
Flatwasher 5/16in Regular
24
2540020
1
Grommet
25
3422219
2
Pin, Snap
26
0100011
AR
Compound, Locking
27
Ref
Nut Options:
27
3300151
AR
Nut, Acorn 1/4in-20NC
27
2080063
AR
Nut, Nylon Lock 1/4in-20NC
28
1060808
AR
Lanyard
29
3911536
1
Screw 5/16in-18NC x 2-1/4in
30
Ref
Screw Options:
30
3911428
2
Screw, Hex 1/4in-20NC x 1-3/4in
30
3900318
2
Screw, Torx Drive 1/4in-20NC x 1-3/4in
31
2940064
NLA
Latch Kit, Snap (use p/n 1001101076)
32
3340612
18
in/46cm
Pad (Chain Gate Only)
33
3422369
2
Pin, Plunger (Chain Gate Only)
34
3641310
1
Rail Weldment (Chain Gate Only)
35
3911424
2
Screw 1/4in-20NC x 1-1/2in (Chain Gate Only)
36
Ref
Screw Options (Chain Gate Only):
36
3911432
4
Screw 1/4in-20NC x 2in
36
3900318
4
Screw, Torx Drive 1/4in-20NC x 2in
