SECTION 6 - DIAGNOSTIC TROUBLE CODES
3121273 – JLG Lift – 6-15
825 LSS HAS NOT BEEN CALI-
BRATED The Load Sensing System has never
been calibrated and the control system
assumes that the platform is over-
loaded. • Empty Platform and Calibrate the Load Sensing System using
the calibration procedure in the LSS Manual.
• HEALTH (Status LED) - ON
8-4 Elevation Switch
DTC FAULT MESSAGE DESCRIPTION CHECK
84109 ELEVATION SWITCH CON-
TACTS DISAGREEMENT The Elevation Switch contacts are the
same (high or low). Since the contacts
should always be complimentary, the
system assumes the platform is Ele-
vated. • Check the wiring and the switch or replace the switch to clear the
fault.
• Health (Status LED) - ON
9-9 Hardware
DTC FAULT MESSAGE DESCRIPTION CHECK
995 POWER MODULE FAILURE -
PERSONALITY RANGE
ERROR The power module detected an out-of-
range or corrupt personality setting • Record all personality settings in ANALYZER -> PERSONALITIES
and ANALYZER -> MACHINE SETUP. Reset control system per-
sonalities to default settings by selecting a different model than
indicated, cycle power then select proper model. Then, enter per-
sonality settings recorded above.
• Health (Status LED) - ON
996 POWER MODULE FAILURE -
INTERNAL ERROR • This is an internal failure.
• Cycle machine, if error still exists, replace System Module.
• HEALTH (Status LED) - FLASHING
998 EEPROM FAILURE - CHECK
ALL SETTINGS The control system detected an
EEPROM failure. • Personalities and Machine Setup settings may be reset to default
values. Check/Correct all settings and re-cycle power to clear dif-
ficulty.
• Health (Status LED) - ON
999 FUNCTION LOCKED OUT -
POWER MODULE SOFT-
WARE VERSION IMPROPER The power module software version is
not compatible with the rest of the sys-
tem. • Re-program or replace with a Version 1.xx module
• Health (Status LED) - ON
9950 POWER MODULE FAILURE -
INTERNAL ERROR • Cycle machine, if error still exists, replace System Module.
• HEALTH (Status LED) - FLASHING
9951 POWER MODULE FAILURE -
INTERNAL ERROR • Cycle machine, if error still exists, replace System Module.
• HEALTH (Status LED) - FLASHING
9952 POWER MODULE FAILURE -
INTERNAL ERROR • Cycle machine, if error still exists, replace System Module.
• HEALTH (Status LED) - FLASHING
9953 POWER MODULE FAILURE -
INTERNAL ERROR • Cycle machine, if error still exists, replace System Module.
• HEALTH (Status LED) - FLASHING
9954 POWER MODULE FAILURE -
INTERNAL ERROR • Cycle machine, if error still exists, replace System Module.
• HEALTH (Status LED) - FLASHING
9955 POWER MODULE FAILURE -
INTERNAL ERROR • Cycle machine, if error still exists, replace System Module.
• HEALTH (Status LED) - FLASHING
9956 POWER MODULE FAILURE -
INTERNAL ERROR • Cycle machine, if error still exists, replace System Module.
• HEALTH (Status LED) - FLASHING
9957 POWER MODULE FAILURE -
INTERNAL ERROR • Cycle machine, if error still exists, replace System Module.
• HEALTH (Status LED) - FLASHING
8-2 LSS - Load Sensing System
(See 3124288 - LSS Manual)
DTC FAULT MESSAGE DESCRIPTION CHECK
