SECTION 1 - SPECIFICATIONS
1-8 – JLG Lift – 3121202
1.10 CRITICAL STABILITY WEIGHTS
DO NOT REPLACE ITEMS CRITICAL TO STABILITY WITH ITEMS
OF DIFFERENT WEIGHT OR SPECIFICATION (FOR EXAMPLE: BAT-
TERIES, FILLED TIRES, COUNTERWEIGHT, ENGINE & PLATFORM)
DO NOT MODIFY UNIT IN ANY WAY TO AFFECT STABILITY.
Table 1-25. Major Component Weights - 600SJ
LB. KG.
Platform Control Console 250 113
Platform Level Cylinder 60 27
Main Boom (Includes Lift Cyl., Rotator, and Support) 3483 1580
Turntable Complete (including engine) 7915 3590
Chassis Complete (w/pneumatic tires) 11300 5126
Chassis Complete (w/foam-filled tires) 12580 5707
Machine Complete (GVW) - 2WD w/pneumatic tires 23500 10660
Machine Complete (GVW) - 4WD w/pneumatic tires 23980 10877
Table 1-26. Major Component Weights - 660SJ
LB. KG.
Platform Control Console 250 113
Platform Level Cylinder 60 27
Main Boom (Includes Lift Cyl., Rotator, and Support) 3783 1716
Turntable Complete (including engine) 9065 4112
Chassis Complete (w/pneumatic tires) 11775 5341
Chassis Complete (w/foam-filled tires) 13055 5922
Machine Complete (GVW) - 2WD w/pneumatic tires 25500 11567
Machine Complete (GVW) - 4WD w/pneumatic tires 25910 11753
Table 1-27. Critical Stability Weights - 600S
LB. KG.
Tire and Wheel (Ballasted Only) Size (15 - 19.5) 253 115
Engine Ford 460 209
Deutz 534 242
Continental 558 253
Counterweight Weight 2900 1315
Platform 6 ft. (1.83 M) 205 93
8 ft. (2.44 M) 230 105
Table 1-28. Critical Stability Weights - 600SJ
LB. KG.
Tire and Wheel (Ballasted Only) Size (15 - 19.5) 253 115
Engine Ford 460 209
Deutz 534 242
Continental 558 253
Counterweight Weight 3500 1588
Platform 6 ft. (1.83 M) 205 93
8 ft. (2.44 M) 230 105
Table 1-29. Critical Stability Weights - 660SJ
LB. KG.
Tire and Wheel (Ballasted Only) Size (15 - 19.5) 253 115
Engine Ford 460 209
Deutz 534 242
Continental 558 253
Counterweight Weight 4650 2109
Platform 6 ft. (1.83 M) 205 93
8 ft. (2.44 M) 230 105
