SECTION 1 - SPECIFICATIONS
3121202 – JLG Lift – 1-3
1.3 PERFORMANCE DATA
Machine Weight (Approximate)
Dimensional Data
Table 1-13. Machine Weight (Approximate)
Model Lbs. Kg
600S - 2WD 22,000 9,979
600SJ - 2WD 23,500 10,660
660SJ - 2WD 25,500 11,567
600S - 4WD 22,510 10,211
600SJ - 4WD 23,980 10,877
660SJ- 4WD 25,910 11,753
Table 1-12. Performance Data
Travel Speed
2WD
4WD
4.5 MPH (7.25 Km/hr.)
4 MPH (6.44 Km/hr.)
Gradeability
2WD
4WD
30%
45%
Table 1-14. Dimensional Data
Machine Height (Stowed) 8 ft. 4.75 in. (2.56 m)
Machine Length (Stowed)
600S Over Drive Axle
600SJ Over Drive Axle
660SJ Over Drive Axle
27 ft. 11.125 in. (8.51 m)
32 ft. 11.75 in. (10.05 m)
35 ft. 2.875 in. (11.40 m)
Machine Width
2WS/2WD
2WS/4WD
4WS/2WD
4WS/4WD
7 ft. 11.375 in. (2.42 m)
7 ft. 11.4375 in. (242 m)
7 ft. 11.4375 in. (2.42 m)
7 ft. 11.375 in. (2.42 m)
Wheelbase 8 ft. 1.50 in. (2.48 m)
Boom Elevation - 600S +60 ft. 2 13/16 in. (18.36 m)
-6 ft. 1 11/16 in. (1.87 m)
Boom Elevation - 600SJ +60 ft. 5 3/4 in. (18.43 m)
-9 ft. 9 3/16 in. (2.98 m)
Boom Elevation - 660SJ +66 ft. 7 5/8 in. (20.31 m)
-11 ft. 5 1/4 in. (3.49 m)
Turning Radius (Inside)
2WS/2WD
2WS/4WD
4WS/2WD
4WS/4WD
12 ft. (3.66 m)
14 ft. 3.875 in. (5.25 m)
5 ft. 5 in. (1.65 m)
5 ft. 3.625 in. (1.22 m)
Turning Radius (Outside)
2WS/2WD
2WS/4WD
4WS/2WD
4WS/4WD
17 ft. 9 in. (5.41 m)
20 ft. 4.6875 in. (6.21 m)
11 ft. 4 in. (3.45 m)
11 ft. 2.6875 in. (3.42 m)
