SECTION 1 - SPECIFICATIONS
1-6 – JLG Lift – 3121202
Hydraulic Oil
NOTE: Hydraulic oils must have anti-wear qualities at least
to API Service Classification GL-3, and sufficient
chemical stability for mobile hydraulic system ser-
vice. JLG Industries recommends Mobilfluid 424
hydraulic oil, which has an SAE viscosity index of
152.
NOTE: When temperatures remain below 20° F (-7° C), JLG
Industries recommends the use of Mobil DTE 13M.
Aside from JLG recommendations, it is not advisable to
mix oils of different brands or types, as they may not con-
tain the same required additives or be of comparable vis-
cosities. If use of hydraulic oil other than Mobilfluid 424 is
desired, contact JLG Industries for proper recommenda-
tions.
1.7 PRESSURE SETTINGS
Table 1-17. Hydraulic Oil
HYDRAULIC SYSTEM OPERATING
TEMPERATURE RANGE
SAE VISCOSITY GRADE
+0° to +180° F (-18° C to +83° C) 10W
+0° F to +210° F (-18° C to +99° C) 10W-20, 10W-30
+50° F to +210° F (+10° C to +210° C) 20W-20
Table 1-18. Mobilfluid 424 Specs
SAE Grade 10W30
Gravity, API 29.0
Density, Lb/Gal. 60°F 7.35
Pour Point, Max -46°F (-43°C)
Flash Point, Min. 442°F (228°C)
Viscosity
Brookfield, cP at -18°C 2700
at 40° C 55 cSt
at 100° C 9.3 cSt
Viscosity Index 152
Table 1-19. Mobil DTE 13M Specs
ISO Viscosity Grade #32
Specific Gravity 0.877
Pour Point, Max -40°F (-40°C)
Flash Point, Min. 330°F (166°C)
Viscosity
at 40° C 33cSt
at 100° C 6.6 cSt
at 100° F 169 SUS
at 210° F 48 SUS
cp at -20° F 6,200
Viscosity Index 140
Table 1-20. Pressure Settings
Setting PSI Bar
Main Relief 3000 207
Upper Boom Lift Down 1500 103
Swing 1700 117
Steer 1800 124
Steer Reliefs - 4WS Front &
Rear 2500 172
Platform Level
Forward
Backward
2800
1800 193
124
Articulating Jib Boom
Up
Down
1500
1200 103
83
