SECTION 2 - PROCEDURES
2-52
– JLG Lift –
3120737
MACHINE SETUP
CALIBRATIONS
MODEL NUMBER
TILT SWITCH
POWER DECK
DECK EXT. LIMIT
FUNCTION CUTOUT
GROUND ALARM
DRIVE CUTOUT
ARMGAURD CUTOUT
FLASH CODE
CURRENT
TEMPERATURE
Displays/adjusts machine model
NOTE: All personalities reset to default when model number
is altered
Displays/adjusts tilt switch presence/function
Displays/adjusts power deck presence
Displays/adjusts deck extension cutout switch presence/
function
Displays/adjusts function cutout switch presence/function
Displays/adjusts ground alarm presence/function
Displays/adjusts drive cutout switch presence/function
Displays/adjusts armgaurd cutout switch presence/function
Displays/adjusts how fault flash codes are indicated
NOTE: Only available at level 1
Displays motor current calibration
Displays heatsink temperature calibration
Table 2-9. Analyzer Menu Structure
TOP LEVEL MENU
SUB LEVEL MENU
ITEM TO BE VIEWED
OR CHANGED
DESCRIPTION DISPLAY
