SECTION 1 - SPECIFICATIONS
1-4
– JLG Lift –
3120737
1.6 SERIAL NUMBER LOCATIONS
For machine identification, a serial number plate is affixed
to the machine. On 2032E2, 2632E2, 2646E2 and 3246E2
the plate is located on the front, center of the machine
frame, on 1532E2 and 1932E2 it is located above the right
rear tire. The serial number will also be stamped on the
front center of the machine frame on all models.
1.7 LIMIT SWITCHES
The machines are equipped with the following limit
switches:
Tilt Alarm
Illuminates a light on the platform and sounds an alarm
when the machine is out of level in any direction, depend-
ing on model.
1532E2/1932E2/2032E2 - 1.5°
2632E2/2646E2/3246E2 - 2°
All Japanese Models - 5°
High Drive Cut-Out
High drive speed is cut out when the platform is raised
above the preset height per model as follows.
Overload Protection (Japanese and French
Specification Only)
When the platform is loaded to 120% of its rated capacity,
the lift up and drive functions are cut out and the platform
alarm (if equipped) is sounded for two seconds on, two
seconds off while the operator tries to activate either lift up
or drive. Remove weight from the platform to restore lift up
and drive functions operation and to silence the alarm (if
equipped)
1.8 CYLINDER SPECIFICATIONS
NOTE: All dimensions are given in inches (in), with the met-
ric equivalent, centimeters (cm), given in parenthe-
ses.
.
Table 1-4. High Drive Cutout
Model
In
m
1532E2
46 - 55
1.2 - 1.4
1932E2
48 - 60
1.2 - 1.5
2032E2
84
2.1
2646E2
102
2.6
2632E2
114
2.9
3246E2
60 - 65
1.5 - 1.7
Table 1-5. Cylinder Specifications
Description
Bore Stroke
Rod
Diameter
Lift Cylinder
(1532E2/
1932E2)
3.00
(7.6)
32.00
(81.2)
2.00
(5.1)
Lift Cylinder
(2032E2)
3.50
(8.9)
38.87
(98.7)
2.00
(5.1)
Lift Cylinder
(2632E2)
3.00
(7.6)
38.94
(99.0)
2.00
(5.1)
Lift Cylinder
(2646E2)
3.00
(7.6)
37.75
(95.8)
2.00
(5.1)
Lift Cylinder
(3246E2)
3.5
(8.9)
38.94
(99.0)
2.00
(5.1)
Steer Cylinder
(All Models)
1.50
(3.8)
6.25
(15.9)
0.75
(1.9)
Brake Cylinder
(All Models)
2.00
(5.1)
1.75
(4.4)
1.00
(2.5)
