SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
6-2 – JLG Lift – 3121297
Dimensional Data
Ground Bearing Pressure
600S
660SJ
67 psi (4.7 kg/cm 2 )
75 psi (5.3 kg/cm 2 )
Maximum Drive Speed 4.25 MPH (6.8 Km/hr.)
Electrical System 12VDC
Gross Machine Weight (Approximate)
600S - 2WS
600S - 4WS
660SJ - 2WD
660SJ - 4WS
21,425 lbs. (9718 kg)
21,800 lbs. (9888 kg)
26,275 lbs. (11918 kg)
25,910 lbs. (12088 kg)
Table 6-1. Operating Specifications
Table 6-2. Dimensional Data
Machine Height (Stowed) 8 ft. 5 in. (2.57 m)
Machine Length (Stowed)
600S
660SJ
28 ft. 4.6 in. (8.65 m)
33 ft. 6 in. (10.21 m)
Machine Width (by tire size)
39x15 - 22.5
15x19.5 tire (non-marking)
41/18LLx22.5X625 (turf)
97 in. (2.46 m)
98 in. (2.49 m)
100 in. (2.54 m)
Wheelbase 8 ft. 1 in. (2.46 m)
Ground Clearance 12 in. (0.3 m)
Platform Height
600S
660SJ
60 ft. 3 in. (18.36 m)
66 ft. 8 in. (20.32 m)
Horizontal Reach
600S
660SJ
49 ft. 6 in. (15.08 m)
56 ft. 9 in. (17.30 m)
Tail Swing 3 ft. 9 in. (1.14 m)
