SECTION 3 - MACHINE CONTROLS AND INDICATORS
3-16 – JLG Lift – 3121297
Platform Control Indicator Panel
(See Figure 3-5., Platform Control Indicator Panel)
1. Tilt Alarm Warning Light and Alarm
This illuminator indicates that the chassis is
on a slope. An alarm will also sound when
the chassis is on a slope and the boom is
above horizontal. If lit when boom is raised or extended,
retract and lower to below horizontal then reposition
machine so that it is level before continuing operation. If
the boom is above horizontal and the machine is on a
slope, the tilt alarm warning light will illuminate and an
alarm will sound and CREEP is automatically activated.
IF TILT WARNING LIGHT IS ILLUMINATED WHEN BOOM IS RAISED OR
EXTENDED, RETRACT AND LOWER TO BELOW HORIZONTAL THEN
REPOSITION MACHINE SO THAT IT IS LEVEL BEFORE EXTENDING
BOOM OR RAISING BOOM ABOVE HORIZONTAL.
NOTE: When the tilt sensor alarm is activated the Drive function
will be disabled if the boom is elevated above horizontal.
2. Platform Overload (If equipped)
Indicates the platform has been over-
loaded.
3. Capacity Indicator
Indicates the maximum platform capacity
for the current position of the platform.
Restricted capacities are permitted at
restricted platform positions (shorter boom
lengths and higher boom angles).
NOTE: Refer to the capacity decals on the machine
for restricted and unrestricted platform capacities.
