SECTION 3 - MACHINE CONTROLS AND INDICATORS
3-2
– JLG Lift –
3121297
Ground Control Station
(See Figure 3-1. and Figure 3-2.)
NOTE: The Function Enable switch must be held
down in order to operate Telescope, Swing,
Lift, Jib Lift, Platform Level Override, and
Platform Rotate functions.
1. Platform Rotate
Provides rotation of the platform.
ONLY USE THE PLATFORM LEVELING OVERRIDE FUNCTION FOR
SLIGHT LEVELING OF THE PLATFORM. INCORRECT USE COULD CAUSE
THE LOAD/OCCUPANT TO SHIFT OR FALL. FAILURE TO DO SO COULD
RESULT IN DEATH OR SERIOUS INJURY.
2. Platform Leveling Override
A three position switch allows the
operator to adjust the automatic self
leveling system. This switch is used
to adjust platform level in situations
such as ascending/descending a
grade.
3. Jib (If Equipped)
This switch provides raising and low-
ering of the jib.
