SECTION 6 - JLG CONTROL SYSTEM
3121284 – JLG Lift – 6-23
H & T LIGHTS:
15*
1
2
NO: No head and tail lights installed.
YES: Head and tail lights installed.
1
* Visible for 340AJ Only
CABLE SWITCH:
16*
1
2
NO: No broken cable switch installed.
YES: Broken cable switch installed.
1
* This item not visible.
LOAD SYSTEM:
17*
1
2
3
4
5
NO: No load sensor installed.
WARN ONLY: Functions in creep, overload lamp lit, platform alarm beeps (5
sec ON, 2 sec OFF).
CUTOUT PLATFORM: All functions cutout, overload lamp lit, platform alarm
beeps (5 sec ON, 2 sec OFF).
CUTOUT ALL: All functions cutout, flash overload light (500mS on, 500mS off),
platform alarm beeps (5 sec ON, 2 sec OFF).
SPECIAL 1: Functions in creep, overload lamp lit, disables telescope out & lift
up, platform alarm beeps (5 sec ON, 2 sec OFF).
1
* Only visible under certain market selections.
* Certain market selections will limit load system options or alter default setting.
FUNCTION CUTOUT:
18*
1
2
3
4
NO: No drive cutout.
BOOM CUTOUT: Boom function cutout while driving above elevation.
DRIVE CUTOUT: Drive & steer cutout above elevation.
DRIVE CUT E&T: Drive & steer cutout above elevation and tilted.
1
* Only visible under certain market selections.
* Certain market selections will limit function cutout options or alter default setting.
GROUND ALARM:
19*
1
2
3
4
NONE: No ground alarm installed.
DRIVE: Travel alarm sounds when the drive function is active.
DESCENT: Descent alarm sounds when lift down is active.
MOTION: Motion alarm sounds when any function is active. 4
DRIVE:
20*
1 4WD: Four wheel drive. 1
* This item not visible.
DISPLAY UNITS:
21*
1
2
METRIC: Celsius, Kilograms, Kilo Pascal. 2
IMPERIAL: Fahrenheit, Pounds, Pounds/in2 2
Table 6-2. Machine Configuration Programing Information
Configuration Label/Digit Number Description
Default
Number
