Product description

New Brunswick Innova® 2000/2050 Shaker

English (EN)

15

modules;

• Provides an operator interface via displays, audible alarm, and connection to the keypad module

(keypad buttons and display graphics).

The optional Temperature Monitor module is designed to “piggyback” onto the main board via an
expansion connector. It has the following functions:

• Control of analog power supplies;
• Signal conditioning of RTD sensor readings;
• Provide remote monitoring capabilities by supplying analog outputs for speed and temperature that are

compatible with chart recorders and analog data acquisition systems.

3.8

Optional features

3.8.1

Temperature/monitor option

A Temperature/Monitor Option is available for installation on the Innova 2000/2050. The ambient
temperature or the temperature of the liquid in any vessel can be measured using the RTD
electronics-based measuring device supplied with this option.

When the option is installed, the LED will display the measured temperatures in 0.1

°C increments. This

option also allows the connection of a chart recorder so that shaking speed and temperature can be
documented. The analog output for shaking speed is 0 – 5

V:

1

V

per

100

rpm.

For

temperature,

the

output

is 0 – 5

V

(0.05

V per °C).

The output can also be connected to a data logging computer with an analog data acquisition card.

3.8.2

Capacity upgrade option

It is possible to significantly increase the capacity of an Innova 2000 shaker with an available capacity
upgrade package (M1190-9910). This option will simply and easily convert an Innova 2000 to an Innova
2050.

This package consists of a 30.5

cm x 40.6

cm

(12

in x 16

in) subplatform to replace the 25

cm x 33

cm

(11

inch x 13

inch) subplatform, and the appropriate counterweight and hardware.

Large capacity Innova 2050 platforms must be used with the increased capacity configuration
(see

Platforms on p. 31).
