Eppendorf Antivibration Pad XL - Manual (Page 10)

19
Weight range [kg] Weight range [US lb]
Antivibration pad from to from to
Antivibration Pad XS 4.5 6.0 9.9 13.2
Antivibration Pad S 6.0 8.0 13.2 17.6
Antivibration Pad M 8.0 10.0 17.6 22.0
Antivibration Pad L 10.0 12.5 22.0 27.6
Antivibration Pad XL 12.5 16.5 27.6 36.4
Ambient temperature 15 °C – 35 °C
Ambient humidity, relative max. 70 %
Weight 750 g
Dimensions Width: 110 mm
Depth: 220 mm
Height: 30 mm
allowable sinking depth 1.5 – 2 mm
additional compression under permanent
maximum allowable load in 5 years
approx. 4 mm
Resting area Microscope footprint plus approx. 100 mm
for each side
6 Technical data
Technical data
6
