Aries Automotive 9504 User Manual
Page 6
SPORT BAR
2013 NISSAN PATHFINDER
Page 5 of 5
4/16/13 (DP)
Driver Side Installation Pictured
Front
Front
(Fig 12) Center of front grill opening pictured
Fig 13
Fig 14
Front
8mm x 30mm
Button Head Bolt
8mm Lock Washer
8mm Flat Washer
12mm x 40mm Hex Bolt
12mm Lock Washer
12mm x 37mm Large
Flat Washer
(2) 6mm x 20mm Hex Bolts
(2) 6mm Lock Washers
(2) 6mm Flat Washers
Complete Installation
(2) 6mm x 20mm Hex Bolts
(2) 6mm Lock Washers
(2) 6mm Flat Washers
Adjust the Center Brace up or down as
necessary to line up with the Sport Bar
