Aries Automotive P2062 User Manual
Page 5
Driver/Left Side Installation Pictured
Frame Mounting Bracket installed with
small factory tow hook and hardware
Insert Double Bolt Plate through the back
of radiator core support cross member
Top Mounting
Bracket
Fig 4A
Fig 6
(Fig 5B) Driver side pictured from above
Front
Fig 4B
The heavy duty factory tow hooks
cannot be reinstalled and will not
clear the Frame Mounting Brackets
Double Bolt Plate
Front
Front
Fig 5A
Page 4 of 7 10/31/2013
