Aries Automotive P4083 User Manual
Page 9
(Fig 18) Driver side Top Bracket
installation pictured
Front
(1) 8mm Button Head Bolt
(2) 8mm Flat Washers
(1) 8mm Nylon Lock Nut
(Fig 19) Passenger side outer Top Bracket pictured
Fig 17
Front
Bolt the Top Outer Bracket
to the Inner Bracket with:
(2) 6mm x 25mm Hex Bolts
(2) 6mm Lock Washers
(2) 6mm Flat Washers
Front
6mm x 25mm Hex Bolts
6mm Lock Washers
6mm Flat Washers
6mm x 25mm Hex Bolts
6mm Lock Washers
6mm Flat Washers
Page 9 of 9
