Chapter 2. specifications, Component identification 2-1, Component identification, 2-1 – Snorkel S2033 User Manual
Page 7: Component identification -1
Chapter 2. Specifications
■
Component Identification
S2033 – 0390076
page 2 - 1
78.5 in
199.4 cm
90 in
228.6 cm
71 in
180.3 cm
91 in
231.1 cm
3.25 in - 8.3 cm Platform Lowered
0.75 in - 1.9 cm Platform Raised
Guardrails
Platform Extension
Upper Controls
Platform
Scissors
Structure
Chassis
Toeboards
36 in
91.4 cm
Front (Steer)
Hydraulic Tray (Right Side)
Battery Tray (Left Side)
Pothole
Protector Skid
Lower Controls
Rear
33 in
83.8 cm
30 in
76.2 cm
Operator’s
Manual Holder
