Chapter 8 – Operation
AB80J/AB85J – 0420453EE 53
Use the following procedure to drain the air line.
. Close the input connector on the chassis.
2. Open the output connector at the platform.
3. Raise the riser and main booms slightly above hori-
zontal.
4. Open the input connector on the chassis.
5. Allow the fluid to drain from the line.
6. Lower the boom and close both connections.
Driving Lights
The optional driving lights are for use in dimly lit areas and
are not intended for driving on public roadways. There are
two headlights at the front of the chassis and two blinking
taillights at the rear of the chassis.
The lights are operational when the machine is set up for
operation from the upper controls and the light switch is
turned on (refer to Figure 8.2).
Figure 8.12 – Upper Controls
If the engine is running, the idle speed increases when
the driving lights are turned on.
Note
Working with the driving or platform work lights on, while
the engine is off, can discharge the batteries enough that
the engine will not start or the emergency power system
will not operate. If the engine cannot be left running while
the lights are on, start and run the engine for at least 15
minutes each hour.
Platform Work Lights
The optional platform work lights are located on the top rail
of the platform next to the upper controls (refer to Figure
8.3). The direction a light points can be adjusted by using
two /
2
″ wrenches to loosen the clamp below the light.
Figure 8.13 – Upper Controls
The lights are operational when the machine is set up for
operation from the upper controls.
Light Switch
