10 S
PECIFICATIONS
ITEM
Platform Size
Platform Extension In
Platform Extension Out
Max. Platform Capacity
Standard
on Extension
Max. No. of occupants
Standard (total)
on Extension
Maximum Wheel Load
Maximum Chassis Inclination
Height
Working Height
Max. Platform Height
Min. Platform Height
Dimensions
Weight
Overal Width
Overal Height
Overal Height, Rails Lowered
Overal Length, Extension In
Overal Length, Extension Out
Drivable Height
Drive Speed
Platform Lowered
Platform Raised
X26N
0,71 m x 2,21 m [28 in. x 87 in.]
0,71 m x 3,20 m [28 in. x 126 in.]
340 kg [750 lbs.]
110 kg [250 lbs.]
3 People Indoors / 1 Person Outdoors (Max Wind Speed 7m/s)
1 person
818 kg [1,800 lbs.]
2.0° side/side – 2.0° front/rear
9,93 m [32.5 ft.]
7,93 m [26 ft.]
1,09 m [43 in.]
2358 kg [5200 lbs.]
0,82 m [32.5 in.]
2,19 m [86 in.]
1,99 m [78.25 in.]
2,35 m [92.5 in.]
3,26 m [128.5 in.]
7,93 m [26 ft.]
0 to 3,2 km/h [0 to 2.0 mph]
0 to 0,8 km/h [0 to 0.50 mph]
11 S
PECIFICATIONS
Energy Source
Motor
System Voltage
Battery Charger
Hydraulic Reservoir Capacity
Maximum Hydraulic Pressure
Hydraulic Fluid 24 Volt Battery Pack (4, 6 Volt 235Ah Batteries, min. wt. 30 kg [66 lbs.] each)
24 Volt 4 Horse Power DC Electric Motor
24 Volt DC
25 A, 110/220 VAC
15 L [4 US Gallons]
207 bar [3000 psi]
Normal Temperature (0° C [>32° F]) ISO #32
Low Temperature (0° C [<32° F]) ISO #32
Extreme Temperature (-17° C [<0° F]) ISO #15
Lift System
Lift Speed
Control System
Drive System
Tyres
Parking Brake
Turning Radius
Maximum Gradeability
Wheel Base
Guardrails
Toe Boards
Ground Clearance
One Single Stage Lift Cylinder
Lift, 42 sec./Lower 40 sec.
Proportional Control Handle with Interlock Switch, Rotary Lift/Drive Switch, and Red
Mushroom Emergency Stop Switch
Dual Front Wheel Hydraulic Motors
381 mm [15 in.
] Diameter Solid Rubber, non-marking
Dual Spring Applied, Hydraulic Release
203 mm [8 in.] Inside
14° [25%]
1,9 m [74.75 in.]
1,1 m [43.25 in.] High
152 mm [6 in.]
89 mm [3.5 in.]
Sound Power Level 69dBA.
Max Wind speed for this machine is Beaufort wind force 4(refer page 7)
Specifications are subject to change without notice. Hot weather or heavy use may affect
performance. Refer to the Service Manual for complete parts and service information.
Meets or exceeds all applicable CE and machinery directive requirements MD98/37/EC.
