Page 7 X Series
L OWER THE G UARDRAILS , X26N
This procedure applies only to the X26N model for the purpose of passing through a standard
double doorway. Guardrails must be returned to proper position before using the machine.
L OWERING P ROCEDURE
1. Ensure that the slide out deck extension is fully retracted and deck pin is locked. Place the
Platform Controls on the platform.
2. Remove and retain the set screws from the side guardrails and the rollout deck guardrails.
3. Pull the four retaining pins and lower the rollout deck guardrail completely.
4. Pull the two retaining pins and lower the rear guardrail until it rests on the stop screws.
5. Pull the two retaining pins and lower the side guardrails completely.
6. Raise the rear guardrail until the retaining pins engage. Remove and retain the stop screws
and nuts from the rear guardrail.
7. Pull the two retaining pins and lower the rear guardrail completely.
R AISING P ROCEDURE
1. Raise the rear guardrail until the retaining pins engage.
2. Install the stop screws and nuts on the rear guardrail and torque to 31 ft. lbs (42 N-m).
3. Pull the two retaining pins and lower the rear guardrail until it rests on the stop screws.
4. Pull the two retaining pins and raise the side guardrails until the tops are level with the rear
guardrail.
5. Raise the rear guardrail until the retaining pins engage.
6. Pull the four retaining pins and raise the roll out deck guardrail until the top is level with the
side guardrails.
7. Hang the controller on the roll out deck guardrail.
8. Install the set screws and torque to 31 ft. lbs (42 N-m).
F OLD D OWN GUARDRAILS , X31N
This procedure applies only to the X31N model for the purpose of passing through a standard
double doorway. Guardrails must be returned to proper position before using the machine.
F OLD D OWN P ROCEDURE
1. Unhook the controller from the side guardrail and place it on the platform.
2. Pull the retaining pin on the front guardrail and rotate inwards.
3. Pull the retaining pin on the rear guardrail and rotate inwards.
4. Starting with the rollout deck guardrails and then the outer guardrails, lift up on each guardrail
and fold inwards.
E RECTION P ROCEDURE
1. Starting with the outer guardrails and then the rollout deck guardrails, raise each guardrail
and drop it down securing it in the vertical position.
2. Rotate the front and rear upper guardrails outward and secure them to the opposite side
guardrails using the retaining pins.
3. Hang the controller on the side guardrail.
W A R N I N G ! !
Before operating machine, guardrails must be securely fastened in their
proper position.
