Snorkel X Series-sn15020-19999 - Manual (Page 13)

Page 13 X Series
FRONT
REAR
FRONT
LEFT MODULE
RIGHT MODULE
061787-001
! DANGER
OF PLATFORM BEFORE OPERATING MACHINE.
THIS BAR MUST BE PINNED IN POSITION ACROSS END
X31N Platform
MAXIMUM SIDE LOAD 200 LBS.
OR 4 OCCUPANTS
PLATFORM LOAD 1000 LBS.
MAXIMUM DISTRIBUTED
WARNING !
101250-003
MAXIMUM SIDE LOAD 150 LBS.
OR 3 OCCUPANTS
PLATFORM LOAD 1000 LBS.
MAXIMUM DISTRIBUTED
WARNING !
101250-004
MAXIMUM SIDE LOAD 150 LBS.
OR 3 OCCUPANTS
PLATFORM LOAD 700 LBS.
MAXIMUM DISTRIBUTED
WARNING !
101250-005
MAXIMUM SIDE LOAD 113 LBS.
OR 2 OCCUPANTS
PLATFORM LOAD 750 LBS.
MAXIMUM DISTRIBUTED
WARNING !
101250-002
1600 LBS.
WHEEL LOAD
MAXIMUM
101252-004
1750 LBS.
WHEEL LOAD
MAXIMUM
101252-005
1850 LBS.
WHEEL LOAD
MAXIMUM
101252-006
EMERGENCY
DOWN VALVE
LOWER PLATFORM
PULL KNOB TO
! DANGER
TIP-OVER HAZARD
MAXIMUM DISTRIBUTED LOAD
250 LBS. OR 1 OCCUPANT
ON EXTENDED DECK
MAXIMUM SIDE LOAD 100 LBS.
061220-002
1 Required
066560-010
1 Required
X20W, X26N, X31N
066560-011
1 Required
X20N
066555-000
1 Required
060197-000
1 Required
066554-000
1 Required
066554-000
1 Required
066550-000
1 Required
061787-001
1 Required
X31N
066558-000
1 Required
X20N, X20W, X26N
005223-003
1 Required
X31N
014222-003-99
2 Required
101250-004
2 Required
X26N
101250-005
2 Required
X31N
101250-002
2 Required
X20N
101250-003
2 Required
X20W
061205-005
1 Required
066522-000
1 Required
066559-000
1 Required
101252-004
1 Required
X20N, X20W
101252-005
1 Required
X26N
101252-006
1 Required
X31N
066561-002
1 Required
X31N
066556-000
2 Required
066561-000
1 Required
X20N, X20W, X26N
101251-000
1 Required
005221-000
1 Required
062562-001
1 Required
066553-000
2 Required
066556-001
4 Required
066552-000
1 Required
010076-001
1 Required
NOTE: Labels can be ordered by using Part Number located by each label. For machines
equipped with options consult the Service Manual.
Proper label installation is required. All of these labels shall be present and in
good condition before operating the work platform. Be sure to read, understand
and follow these labels BEFORE operating the work platform.
