S PECIFICATIONS
Specifications are subject to change without notice. Hot weather or heavy use may reduce performance.
Meets or exceeds all applicable requirements of OSHA and ANSI A92.6-1999
ITEM X20N X20W X26N X31N
Platform Size w/ Extension
28 in. x 87 in.
[0,7 m x 2,21 m]
44 in. x 87 in.
[1,12 m x 2,21 m]
46.25 in. x 87 in.
[1,17 m x 2,21 m]
46.25 in. x 87 in.
[1,17 m x 2,21 m]
Max. Platform Capacity
Standard 750 lbs. [340 kg] 1000 lbs. [453 kg] 1000 lbs. [453 kg] 700 lbs. [318 kg]
on Extension 250 lbs. [110 kg] 250 lbs. [110 kg] 250 lbs. [110 kg] 250 lbs. [110 kg]
Max. No. of occupants
Standard (total) 2 people 4 people 3 people 3 people
on Extension 1 person 1 person 1 person 1 person
Height
Working Height 26 ft. [7,9 m] 26 ft. [7,9 m] 32 ft. [9,75 m] 37 ft. [11,28 m]
Max. Platform Height 20 ft. [6,1 m] 20 ft. [6,1 m] 26 ft. [7,92 m] 30.5 ft. [0,8 m]
Min. Platform Height 38 in. [0,97 m] 38 in. [0,97 m] 43 in. [1,1 m] 48 in. [1,2 m]
Dimensions
Weight 3,828 lbs. [1656 kg] 4,273 lbs. [1858 kg] 4,747 lbs. [2072 kg] 5480 lbs. [2485,7 kg]
Overall Width 32.5 in. [0,83 m] 48 in. [1,22 m] 48 in. [1,22 m] 48 in. [1,22 m]
Overall Height 78.5 in. [2 m] 78.5 in. [2 m] 83.5 in. [2,1 m] 88.5 in. [2,25 m]
Overall Length, Extension In 92.5 in. [2,3 m] 92.5 in. [2,3 m] 92.5 in. [2,3 m] 92.5 in. [2,3 m]
Overall Length, Extension Out 128.5 in. [3,26 m] 128.5 in. [3,26 m] 128.5 in. [3,26 m] 128.5 in. [3,26 m]
Drivable Height 20 ft. [6,1 m] 20 ft. [6,1 m] 26 ft. [7,93 m] 30.58 ft. [9,3 m]
Drive Speed
Platform Lowered 0 to 2.0 mph [0 to 3,2 km/h]
Platform Raised 0 to 0.62 mph [0 to 1 km/h]
Energy Source 24 Volt Battery Pack (4-220 Amp Hour, 6 Volt Batteries, min. wt. 62 lbs. [28,12 kg] each)
Motor 24 Volt 4 Horse Power DC Electric Motor
System Voltage 24 Volt DC
Battery Charger 25 AMP, 110/220 VAC
Battery Duty Cycle 25% for 8 Hours
Hydraulic Tank Capacity 4 Gallons [15,2 l] 4 Gallons [15,2 l] 4 Gallons [15,2 l] 5 Gallons [19 l]
Maximum Hydraulic Pressure 3000 psi [206,8 bar]
Lift System One Single Stage Lift Cylinder One Single Stage Lift Cylinder One Single Stage Lift Cylinder
Two Single Stage Lift
Cylinders
Lift Speed Raise, 35 sec./Lower 30 sec. Raise, 40 sec./Lower 30 sec. Raise, 45 sec./Lower 40 sec. Raise, 65 sec./Lower 40 sec.
Control System Control Handle with Interlock Switch, Rotary Drive/Lift Switch, and Red Mushroom EMERGENCY STOP Switch
Drive System Dual Front Wheel Hydraulic Motors
Tires 15 in. [381 mm] Diameter Solid Rubber, non-marking
Parking Brake Dual Spring Applied, Hydraulic Release
Turning Radius 8 in. [254 mm] Inside
Maximum Gradeability 23% [13°] 23% [13°] 22% [12°] 20% [11° ]
Wheel Base 74.75 in. [1,9 m]
Guardrails 40 in. [1,02 m] High
Toeboard 6 in. [152 mm] High
