UNLOADING
1. Unsecure the unit.
2. Remove loading handle from its storage posi-
tion on left side of mast. Secure handle in base
of unit using clevis pin (Figure 6).
3. Roll the unit back until the rear wheels are off
the edge of the tailgate or vehicle bed.
4. Pull downward on the loading handle, allowing
the unit to slide on the loader. As the unit stops
sliding on the loader, it will pivot on the loader
to an upright position. Gradually counterbal-
ance the unit’s weight by applying an upward
force on the loading handle. This allows the
unit to settle gently on the wheels, avoiding
undue impact on the unit.
5. Return the loading handle to its storage position.
DC Models
Reinstall the battery box and reconnect the plug
making certain it is fully engaged.
Passage Through A Doorway
When completely lowered, UL20 will pass through
a standard doorway without tilting back.
Figure 8: Tilting machine onto or off of a vehicle
Figure 9: Pushing machine into transport position
