22
Emergency Stop Buttons: Fig.12
Emergency Slew: FIG. 14
Emergency Lowering: FIG. 16 & 17
Battery Isolating: FIG. 18
1. Fully lower all the booms.
2. Manual Outriggers – wind up the screw jacks as far as they will go, unlock the spring
bolts by pulling them out then lift the outriggers until they are fully stowed.. The spring
bolt can then be released and the outrigger adjusted to lock the sping bolt in its hole.
Ensure BOTH spring bolts on each Outrigger arm are fully
located.
!
Repeat this procedure for each outrigger.
Hydraulic Outriggers – Raise the outriggers by simultaneously depressing the ‘Black’
motor run button near the outrigger control valve and using the appropriate control
levers, two at a time, alternating between the cage and tow bar end until the road w
heels are in contact with the ground.
3. Only when the road wheels are in contact with the ground should the unit be lowered
further until the jockey wheel makes contact with the supporting surface.
Now fully raise the outriggers until they are in the stowed position.
4. Switch off the platform and ensure all loose item covers are secure before towing the
unit.
STOWING THE MACHINE
