12
ITEM
Platform Size (Inside Toeboards)
Standard
w/ Extension
Max. Platform Capacity
Standard
w/ Extension
on Extension
Max. No. Of occupants
Standard
on Extension
Height
Working Height
Max. Platform Height
Min. Platform Height
Dimensions
Weight
Overall Width
Overall Height
Overall Length
Driveable Height
Surface Speed
Platform Lowered: Diesel
Electric
Platform Raised: Diesel
Electric
System Voltage
Battery Charging
Hydraulic Tank Capacity
Maximum Hydraulic System
Pressure
Hydraulic Fluid
Normal Use (>32 °F [0 °C])
Low Temp. Use
(-10 to 32
°F [-23 to 0 °C])
Lift System
Fuel Tank Capacity
Lift Speed
Diesel
Electric
Power Source
Drive Control
Control System
Horizontal Drive
Tyres
Parking Brake
Turning Radius (inside)
Maximum Gradeability
Wheel Base
Guardrails
Toeboard
064672-002
12/99 D
Safety Rules and Operating Instructions
Safety Rules and Operating Instructions
Specifications*
SL26N
1.46 m x 3.59 m [57.5 in. x 141.5 in.]
1.46 m x 4.61 m [57.5 in. x 181.5 in.]
567 kg [1250 lbs.]
567 kg [1250 lbs.]
227 kg [500 lbs.]
5 people
2 person
9.75 m [32 ft.]
7.93 m [26 ft.]
1.5 m [59 in.]
2871 kg
1.83 m [72 in.], with standard tyres
2.40 m [94.5 in.]
3.79 m [149 in.]
7.93 m [26 ft.]
0 to 5.9 km/h [0 to 3.7 mph]
0 to 4.3 km/h [0 to 2.7 mph]
0 to .8 km/h [0 to .5 mph]
0 to .6 km/h [0 to .4 mph]
24 Volt DC
40 Amp 110/220 V 50 Hz Charger, 42 Amp Altenator
45.5 L [12 gal.]
172 bar [2500 psi]
ISO #46
5W-20 Motor Oil
One Single Stage Lift Cylinder
36 L (9.5gal.)
Raise, 20 sec./Lower, 35 sec.
Raise, 33 sec./Lower, 35 sec.
20 HP Kubota Diesel, 3 Cylinder, water Cooled Engine,
Two 24V Electric Motors, Eight 6V 220 Amp/Hr Batteries
Proportional
Joystick Controller with Interlock Lever and Thumb Rocker
Steering, Toggle Selector and Emergency Stop Switches
Dual Rear Wheel, Hydraulic Motors
26x12 - 12NHS Super Terra-Grip, With Trac-Seal
Spring Applied, Hydraulic Release
2.97 m [9 ft. 9 in.]
Diesel: 12
° [21%] Electric: 11 ° [20%]
2.54 m [100 in.]
1.11 m [43.5 in.] high, Fold Down with Gate
152 mm [6 in.] High
SL30N
1.46 m x 4.22 m [57.5 in. x 166.25 in.]
N/A
453 kg [1000 lbs.]
N/A
N/A
4 people
N/A
10.97 m [36 ft.]
9.14 m [30 ft.]
1.5 m [59 in.]
3013 kg
1.83 m [72 in.], with standard tyres
2.40 m [94.5 in.]
4.39 m [173 in.]
10.97 m [30 ft.]
0 to 5.9 km/h [0 to 3.7 mph]
0 to 4.3 km/h [0 to 2.7 mph]
0 to .8 km/h [0 to .5 mph]
0 to .6 km/h [0 to .4 mph]
24 Volt DC
40 Amp 110/220 V 50 Hz Charger, 42 Amp Altenator
45.5 L [12 gal.]
172 bar [2500 psi]
ISO #46
5W-20 Motor Oil
One Single Stage Lift Cylinder
36 L (9.5gal.)
Raise, 23 sec./Lower, 35 sec.
Raise, 33 sec./Lower, 35 sec.
20 HP Kubota Diesel, 3 Cylinder, water Cooled Engine,
Two 24V Electric Motors, Eight 6V 220 Amp/Hr Batteries
Proportional
Joystick Controller with Interlock Lever and Thumb Rocker
Steering, Toggle Selector and Emergency Stop Switches
Dual Rear Wheel, Hydraulic Motors
26x12 - 12NHS Super Terra-Grip, With Trac-Seal
Spring Applied, Hydraulic Release
2.97 m [9 ft. 9 in.]
Diesel: 12
° [21%] Electric: 11 ° [20%]
2.54 m [100 in.]
1.11 m [43.5 in.] high, Fold Down with Gate
152 mm [6 in.] High
* Specifications subject to change without
notice.
Hot weather or heavy use may reduce
performance.
Meets or exceeds all applicable requirements
of OSHA and ANSI A92.6-1999
Refer to Service Manual for complete parts
and service information.
