Chapter 2 – specifi cations, Component identifi cation – Snorkel AB85RJ User Manual
Page 7
AB85RJ – 0421533
3
Chapter 2 – Specifi cations
Component Identifi cation
Right Side
Chassis
Lower
Controls
Upper Controls
Fuel Tank
LP Fuel Tank
Left Side
Platform
Main Boom
Tip Boom
Hydraulic Fluid Tank
And Filter
Battery Disconnect
Switch
Batteries
Engine
Platform
Foot Switch
Operator’s
Manual
Emergency
Lowering
Pump
Rear
Front
Interactive Link
Front
Rear
Jib
Riser Boom
Riser
