Snorkel AB48HSRT-sn4611+ - Manual (Page 17)

15
1. Ensure that the booms are fully lowered and located in the front prop, all
outriggers are fully raised and that the machine is manoeuvrable.
2.
Climb into the driving seat and fasten seat belt across your lap.
3.
Insert the ingition Key and turn part way, intil the Pre-Heat lamp h a s
illuminated. (Ref, Section G)
4. When the lamp goes out and the pre-heat sequence has ended,
complete the turn to start the ignition and release when the
engine starts.
5.
When the engine is running, place your foot on the footbrake and release
the park brake.
6
. Select a
direction of travel, by
moving the left hand stalk on the
steering wheel in the direction of intended travel.
7.
Remove your foot from the footbrake and gently press the accelerator
pedal until the vehicle starts to move.
8. To slow or stop the vehicle, remove your foot from the accelerator pedal
and press the footbrake.
9.
When the vehicle comes to a complete stop, select neutral drive and
engage the park brake.
DRIVING THE VEHICLE
SECTION
H
Do NOT use the Steering wheel to pull yourself into the cab as
this could cause damage to the vehicles Steering system.
!
Do NOT hold the ignition on for more than 10 seconds.
If the engine does not start repeat the Pre-Heat sequence.
!
Foot Brake
Accelerator
Park Brake
The vehicle battery must be able to deliver 12volts.
Ensure you are familiar with all of the vehicle controls before
you attempt to travel at speed.
1
