PPM-8098 JK WELD ON HD REAR LOWER SPRING
MOUNTS
Version 1
GENERAL NOTES:
• These instructions are also available on our website; www.synergymfg.com.
Check the website before you begin for any updated instructions and additional
photos for your reference.
• These heavy duty lower coil mounts are meant to replace the original brackets on
the stock or similar size axle tube. They enable you to fix the angle of the lower
spring mount after you have rotated the pinion up for a CV drive line. They also
incorporate a plate to keep the springs from dislocated from the lower spring
mount.
• The installation of this bracket requires the complete removal of the stock lower
coil mounts with a cut off wheel and grinder. The new brackets must be welded
to the axle tube. An experienced fabricator/welder is recommended to properly
install this bracket.
1. Remove any bumpstop extension brackets that are bolted to the lower bumpstop pads
on the rear axle
2. Take a reference measurement of the ride height of the vehicle between the bumpstop
pad and upper jounce stop mounting cup. Enter that measurement here____________
3. Support the vehicle on jack stands and remove the coil springs
4. Support the rear axle on a jack and raise back to the ride height measurement form
step 2
5. Measure the angle of the lower bump stop pad, enter that angle here______________
