SYNERGY MFG. 870 INDUSTRIAL WAY, SAN LUIS OBISPO, CA (805) 242-0397
INSTALLATION INSTRUCTIONS
PPM-8076 / PPM-8076-RHD JEEP JK 2.0”
BOLT ON REAR TRACK BAR BRACKET
GENERAL NOTES:

These instructions are also available on our website at www.synergymfg.com
Check the website for any updated instructions and additional photos for
reference.

Simple hand tools are required for installation.

Although it is possible to install these with vehicle sitting on ground, it will be
much easier to install with the suspension drooped out.
 You must use a minimum of 2” bump stop extension, 8058-20 (2”) or 8058-30
(3”) or 8058-40 (4”) to prevent the track bar from contacting the exhaust at full
bump.
 2.0” diameter shocks are the maximum size allowable with this track bar bracket,
any larger and rubbing will occur between the track bar bracket and the shocks
during articulation.

Note; these instructions cover installation on a LHD vehicle. Installation on a
RHD vehicle is the same with everything mirrored on the right side of the chassis.
1) Remove the factory rear track bar from the axle and loosen the track bar from the
frame bracket to allow the track bar to rotate out of the way. Secure the track bar up
and out of the way with a bungee cord or something similar.
a. All track bar bolt hardware is a 21mm or 13/16” wrench size.
b. Retain all factory track bar hardware as it will be re-used when reinstalling
the track bar.
