SYNERGY MFG. 870 INDUSTRIAL WAY, SAN LUIS OBISPO, CA (805) 242-0397
PPM-8055 JK FRONT TRACK BAR RELOCATION
BRACKET
Version 2.0
GENERAL NOTES:

These instructions are also available on our website; www.synergymfg.com.
Check the website before you begin for any updated instructions and additional
photos for your reference.

The installation of this bracket should not require any cutting or drilling.

This bracket should be used with the PPM-8001 drag link flip kit.
 You must use a minimum of 3” of front bump stop extension, PPM-8057-30 (3”)
or PPM-8057-40 (4”) to prevent the track bar and bracket from hitting the bottom
of the frame at full jounce travel.
PARTS LIST:
 (1) 805501 JK Front Track Bar Bracket
 (1) 805502 JK Sway Bar Tab
 (1) 805503 JK Front Track Bar Spacer 1.50”
 (1) 805504 JK Front Track Bar Spacer 1.40”
 (2) 3/8-24 UNF x 1” long hex head bolt
 (2) 3/8-24 UNF Stover Nut
 (6) 3/8” Flat Washer
 (2) 3/8-16 UNC Nylock Nut
 (2) ½-20 UNF x 3” long hex head bolt
 (2) ½-20 UNF Stover Nut
 (5) ½” Flat Washer
 (1) 9/16-18 UNF x 3” long hex head bolt
 (1) 9/16-18 UNF Stover Nut
 (2) 9/16” Flat Washer
 (1) U-Bolt, 1.125” Radius x 4” long
APPROXIMATE INSTALL TIME: 1-1.5 HOURS
Instructions :
1. Remove the factory front track bar from the axle bracket and loosen the track bar
from the frame bracket to allow the track bar to rotate out of the way. Secure the
track bar up and out of the way with a bungee cord or something similar.
