Technical data – Lukas P 630 Lite User Manual
Page 41
41
13. Technical data
NOTE:
The following tables contain only the technical data required for standard
acceptance.
Additional data concerning your unit can be obtained from LUKAS on request.
The limitation of the max.
¿ ll quantity of the hydraulic tank results from the
"operability at a slant" prescribed in the standards.
Because all values are subject to tolerances, there may be small differences between the
data for your device and the data in the following tables!
The values may also differ because of reading inaccuracies and/or tolerances in the
measuring equipment used.
13.1 Power unit
13.1.1 Basic dimensions in mm [inch]
Dimensions of the power unit P 630 lite:
