12
5.2 Installation of the power unit
6
1 Petrol tank
2 Hydraulic
À uid tank
3 Engine
4 Hydraulic pump with
control valve
5 Speed adjusting lever
6 Carrying handle, swivelling
7 Cable starter
8 Valve control lever
9 Coupling connection
10 Fuel tank cover
11 Filler cover hydraulic
À uid
12 Base
13 Rubber buffer
14 Air
¿ lter
15 Choke
16 Fuel tap
17 ON/OFF switch (engine
switch)
18 Connection pressure line
19 Connection tank line
20 Engine oil
¿ lling cap/
dipstick
21 Fill level indicator
13
11
2
7
3
12
4
5
10
14
1
Equipment rear
15 16 17
8
21
20
9
19
18
P 630 lite
