26
12.2 Combi tools
* 1 MPa = 10 bar
** Required volume of hydraulic fluid in the hydraulic power pack for operating the
tool (differential volume piston/rod side)
type LKS 35 FI LKS 35 FI
ref.no. 113070000 173070000
dimensions l x w x h
(w/o connection hoses)
[mm] 762 x 210 x 195
[in.] 30.00 x 8.27 x 7.68
max. cutting opening
[mm] 265
[in.] 10.43
max. cutting force
(rear end of the cutting surface)
[kN] 418
[lbf.] 93,975
max. spreading distance
(on the blade tips)
[mm] 360
[in.] 14.17
max. spreading force
(25mm from the tips)
[kN] 49,5
[lbf.] 11,129
weight incl. hydraulic fluid
[kg] 17,0
[lbs.] 37.5
max. operating pressure
[Mpa] * 70
[psi.] 10,153
min. needed volume
of hydraulic fluid
[l] ** 0,066
[gal.-US] 0.017
coupling system quick-disconnect-coupling mono-coupling
12.3 Tightening torques for pivot bolt
type LS 311 FI LS 330 FI LKS 35 FI
pivot bolt M 24 x 1,5 M 24 x 1,5 M 24 x 1,5
wrench size
[mm] 36 36 36
[in.] 1.42 1.42 1.42
torque
[Nm] 120 +10 120 +10 120 +10
[lbf.in.] 1,062 + 89 1,062 + 89 1,062 + 89
