24
Since all values are subject to tolerances, minor differences may occur between the data on
your equipment and the data in the following schedules!
12.1 Cutting tools
Technical Data 12.
* 1 MPa = 10 bar
** Required volume of hydraulic fluid in the hydraulic power pack for operating the
tool (differential volume piston/rod side)
type LS 330 FI STREAM LS 330 FI STREAM
ref.no. 112070000 172070000
dimensions l x w x h
(w/o connection hoses)
[mm] 733 x 210 x 195
[in.] 28.85 x 8.27 x 7.68
max. cutting opening
[mm] 228
[in.] 8.98
max. cutting force
(rear end of the cutting
surface)
[kN] 616
[lbf.] 138,489
weight incl. hydraulic
fluid
[kg] 17,7
[lbs.] 39.0
max. operating pressure
[Mpa] * 70
[psi.] 10,153
min. needed volume
of hydraulic fluid
[l] ** 0,098
[gal.-US] 0.026
coupling system
quick-disconnect-
coupling
mono-coupling
