preset number to be saved. This is similar for the alarms; however, the number is only visible
if Multi Alarm is turned on, otherwise the Sony Set table is automatically mapped to the single
alarm input (tamper switch).
Mapping to nothing saves the table information but it is not automatically called up at any
time by the camera. For Nothing, and Normal mapping, the number option becomes
unavailable. This submenu can only be exited through the Save and Exit or Exit Without Saving
option.
The Setup Commands option loads in the table selected, showing 4 commands per page, each
displaying the selected command type and its associated value. These are set as with any
other options in the menu by selecting the appropriate line, Right, then using up and down to
move through the list.
Changing the command type will change the setting for that type to the default value so the
command type should be selected first and then the options second.
The list of available controls and values is below.
Setting
Options
Mapped To
Nothing / Normal / Preset with PTZ/ Preset without PTZ/ Alarm
Number
N/A / Preset 1-64 / Multi Alarm 1-12
No. of Commands
1-10
Setting
Values Available
Camera Zoom
0-28672
Digital Zoom
ON / OFF
Set Focus
4096-49152
Focus Mode
Auto/Manual
Focus Control
One Push Trigger / Force Infinity
AF Sensitivity
High / Low
Focus Near Limit
4096-49152
White Balance
Auto / Indoor / Outdoor / One Push / Auto Tracing /Manual / One
Push Trigger
Red Gain
Reset / Plus 1 / Minus 1
Red Gain Set
0-255
Blue Gain
Reset / Plus 1 / Minus 1
Blue Gain Set
0-255
Exposure
Auto / Manual / Shutter Priority / Iris Priority / Gain Priority /
Bright / Shutter / Auto / Iris Auto / Gain Auto
Slow Shutter
Auto / Manual
Shutter
Reset / Plus 1 / Minus 1
Shutter Set
0-19
Iris
Reset / Plus 1 / Minus 1
Iris Set
0-19
Gain
Reset/Plus 1/Minus 1
Gain Set
0-7
Brightness
Reset / Plus 1 / Minus 1
Brightness Set
0-19
