PREASSEMBLY CHECK
Once the stock helical gear has been removed from the case, place the stock gear
onto the new rear output shaft. Place a straightedge across the shoulder of the new
shaft as shown (Fig.1). Verify clearance between the straightedge and the grinded
surface of the gear. The gear shoulder on the shaft SHOULD NOT be any higher
than the two grinded gear surfaces.
FIG: 1
