J.P.Instruments Fuel Flow Installation Manual
Report # 760
for EDM-760 temperature indicating system with Fuel Flow Option Appendix - A
Page Page 7 of 14 Rev NC :
Date 07/20/99
SPECIFICATIONS TRANSDUCER
Fuel Flow Transducer, Standard (FXT-201)
Range: 0.6 to 60 GPH
Linearity: %1 (8 to 60 GPH)
K Factor Approx. 29,000
Pressure Drop: 1.2 PSI at 30 GPH
4.8 PSI at 60 GPH
Working Press: 200 PSI
Min. Burst Press: 2000 PSI
Temp. Range: -65'C to 125'C
Fuel Ports: 1/4" Female NPT
