Rock-Slide Engineering TJ REAR BUMPER - Manual (Page 2)

INSTALLATION INSTRUCTION RSEI 105
PARTS LIST
QTY DESCRIPTION QTY DESCRIPTION
1 Rear Bumper 1 1'' Washer
1 Tire Carrier 1 Aluminum Cap
1 Tire Mount Bracket 1 O-Ring (140)
1 Tailgate Plate 1 1.25'' Rubber Bumper
2 Nutserts 2 5/16” Washers
1 Seal (5121) 2 5/16'' x 1.5” bolts
1 Left Hand Heim Joint 2 Bearing (Set 5)
1 Right Hand Heim Joint 2 1/2'' x 3.5'' Bolt
1 Left Hand Jam Nut 1 1/2'' x2.5” Bolt
1 Right Hand Jam Nut 3 Lug Studs
1 Turn Buckle 6 7/16'' x 1.5'' Bolt
1 1” Nut 4 7/16'' Nut
1 5/8'' x 3.5'' Bolt 10 7/16” Washer
1 5/8'' Nut 7 1/2'' Washer
