INSTALLATION INSTRUCTION RSEI 101
PARTS LIST
QTY DESCRIPTION QTY DESCRIPTION
1 Rear Bumper 1 1'' Washer
1 Tire Carrier 1 Aluminum Cap
1 Tire Mount Bracket 1 O-Ring (140)
1 Tailgate Plate 1 1.25'' Rubber Bumper
1 Mount Adjust Bracket 1 8mm x 1'' Socket Bolt
1 Seal (5121) 2 5/8'' Washer
1 Left Hand Heim Joint 2 Bearing (Set 5)
1 Right Hand Heim Joint 3 1/2'' x 3'' Bolt
1 Left Hand Jam Nut 3 1/2'' Nut
1 Right Hand Jam Nut 3 Lug Studs
1 Turn Buckle 4 7/16'' x 4'' Bolt
1 1/2'' x 2.5'' Bolt 4 7/16'' Nut
1 5/8'' x 3.5'' Bolt 4 1/2'' x 3/8'' Spacer
1 5/8'' Nut 10 1/2'' Washer
1 1'' Nut 12 7/16'' Washer
*If any parts listed are missing or damaged please call Rock-Slide Engineering @
435-752-4580 prior to installation
