Hornady Lock-N-Load Rifle Bullet Feeder - Manual (Page 5)

Hopper Installation
Slide the hopper onto the Top Support Tube (29), with the
hopper opening facing the front of the bench.
Place a ¼-20 x 2 SHCS Bolt (29) with one ¼" Flat Washer (30)
through the middle and bottom holes of the Bullet Feed Hopper
(29) and the Top Support Tube (37).
Place a ¼" Flat Washer (30) then a ¼-20 Hex Nut (14) onto the
end of each of the ¼-20 x 2 SHCS Bolts (29) and tighten snug.
Hopper Setup
Loosen ¼-20 Thumb Screw (10) and the Lock Nut (7) on the
Adjustment Screw (6).
Raise the Bullet Guide Plate (11) by turning the Adjustment
Screw (6) clockwise far enough to hold a bullet base first
against the Bullet Guide Plate (11). You will need to adjust the
Bullet Guide Plate up or down to get a bullet to feed base first,
but fall off if the bullet is nose first. Tighten the Lock Nut (7)
once set.
Place two bullets on the Bullet Feed Wheel (13) under the Bullet
Wipers (27), base down against the Bullet Guide Plate (11).
Loosen the Wiper Thumb Screw (28) and Wing Nuts (25) and
adjust the wipers so that a base-down bullet tip passes under
the wiper, but a tip-down bullet gets kicked out.
4
5
6
7
4
5
7
6
Thumb Screw
Lock Nut
Lock Nut
Wing Nut
Bullet Wiper
Feed Wheel
Feed Wheel
Bullet Guide
Plate
Bullet Guide
Plate
Bullet Thumb
Screw
Adjustment
Screw
Adjustment
Screw
Flat Washer
Bolt
Nut
- 5 -
